Teledyne DALSA introduces Z-Trak 3D Apps Studio, a suite of software tools developed for in-line 3D machine vision applications. Designed to work with Teledyne DALSA’s Z-Trak family of laser profilers, it simplifies 3D measurement and inspection tasks on production lines. Capable of handling 3D scans of objects with varied surface types, sizes and geometric features, Z-Trak 3D Apps Studio is ideal for factory automation applications across a wide range of industries including electric vehicles (EV batteries, motor stators etc.), automotive, electronics, semiconductors, packaging, logistics, metal fabrication, lumber and many more.
Key Takeaways:
- Z-Trak 3D Apps Studio features streamlined tools for measuring object thickness, inspecting glue-beads, weld seams, and identifying defects on flat, inclined and curved surfaces on machined, assembled, or extruded parts. It also includes anchoring and data enhancement features like reflection elimination to ensure reliable and repeatable results under diverse operating conditions.
- Teledyne’s Z-Trak family of laser profilers features various multi-sensor topologies to enhance the field of view while preserving height resolution, to overcome occlusion or to provide a 360° view of objects for inspection and measurements. Z-Trak 3D Apps Studio simultaneously acquires, processes, and analyzes 3D scans and 2D gray scale images (reflectance data) all with 3D visualization capabilities.
