Enhanced Complex Modeling Workflows for Increased Productivity

Parasolid v27.1 delivers enhancements to support efficiency and effectiveness in complex modeling workflows

Parasolid v27 1 tcm1023 232487 54a6c81c0285f
siemens logo 2017 claim petrol rgb 5a27089b547d9

Plano, TexasJan. 2, 2015Parasolid v27.1 from Siemens PLM Software delivers numerous enhancements to support efficiency and effectiveness in complex modeling workflows. Parasolid is a 3D solid modeling component software used as the foundation of Siemens PLM’s NX and Solid Edge products. These new enhancements enable application developers to deliver step changes in productivity to end-users. Parasolid provides high-level geometric functionality that can be most productively and robustly achieved at the kernel modeler level, which allows application developers to focus on their customers’ other requirements. Enhanced areas in Parasolid v27.1 include blending, surfacing, modeling support and platform support.

These enhancements are in addition to numerous improvements targeted at specific industries and workflows.

Blending

Parasolid v27.1 provides extended control over the shape of blends. This extended control enables end-users to get the exact shape required for functional or aesthetic purposes, which demonstrates the use of blending as a complex modeling technique beyond its historical role of simply rounding off model edges. Blending enhancements allow you to:

  • More easily control the profile of G2 face blends by providing constant depth and skew values.
  • Define variable radius edge blend parameters over a chain of edges—in addition to edge by edge—to give a smoother result.

Surfacing

Parasolid v27.1 enhancements give more flexibility to reach the desired design results within an operation, which eliminates multiple operations. The surfacing enhancements allow you to:

  • Replace sharp mitered corners created by sweeping a profile along a sharp non-G1 path with rounded corners.
  • Align parameterization of extruded surfaces with the extrude direction.
  • Optimize parameterization of the new face when replacing a set of faces with a single face.
  • Sweep a profile along a path with the option to extend the path beyond one or more faces used to lock the profile.
  • Sweep a solid tool along a path and specify that a face or set of faces of the tool are unimportant to the result, and that their precise sweep should be replaced by a simpler capping surface.

Modeling Support

Parasolid v27.1 includes changes to existing functionality to assist detailed modeling in fewer steps. Parasolid v27.1 modeling support enhancements allow you to:

  • Imprint a set of curves that are coincident with a face as a group, which improves performance and robustness.
  • Imprint a curve onto faces of a body with greater influence by controlling how to imprint onto hidden faces.

Platform Support

In response to customer requests, Parasolid v27.1 and Bodyshop v27.1 for Microsoft Windows are now compliant with the Microsoft Security Development Lifecycle, which is a set of standards designed to reduce incidences of security vulnerabilities in software. This is a precautionary platform security enhancement as there are no reports of security vulnerabilities in these libraries.
